Thickness: 0.1-300mm, or as customer’s requirements.
Width: 100-3000mm, or as customer’s requirements.
Material：1050, 1060, 1070, 1080, 1100, 2011, 2014, 2017, 2024, 2A12, 2A16, 2A06, 3002, 3003, 3004, 3104, 3204, 3030, 3A21, 5005,5025, 5040, 5052, 5056, 5083, 5086, 5182, 5754, 5A05, 6003, 6060, 6061, 6082, 6083, 6063, 6061, 7003.
Standard: JIS, AISI, ASTM, GB, DIN, EN, etc.
Stock: 8000 Ton/Month.
Quality control: Third Part Inspection is acceptable.
Delivery Time: Within 3 days for our stock size, 15-20days for our production.
5754 aluminum coil is a typical 5 series Al-Mg anti-rust alloy. Because it contains the main alloy component Mg, it has excellent corrosion resistance, rust resistance, high fatigue strength, good weldability and workability. In practical applications, 5754 aluminum alloys with different heat treatment conditions are widely used in high-speed railway noise barriers, tank car tanks, high-grade alloy doors and windows, car roof/bottom guards, ship structures and offshore facilities, etc., becoming a very popular product in the aluminum market! Similarly, 5754 aluminum coil is also a non-heat-treated alloy, which uses cold working to improve its mechanical properties.
| Product Name | 5754 Aluminum Coil |
| Material | 1050, 1060, 1070, 1080, 1100, 2011, 2014, 2017, 2024, 2A12, 2A16, 2A06, 3002, 3003, 3004, 3104, 3204, 3030, 3A21, 5005,5025, 5040, 5052, 5056, 5083, 5086, 5182, 5754, 5A05, 6003, 6060, 6061, 6082, 6083, 6063, 6061, 7003 |
| Temper | H111 H112 H116/H321 H12/H22/H32 H14/H24/H34/H16/H26/H36 H18/H28/H194,etc |
| Standard | ASTM, JIS, SUS, EN, DIN, GB, etc. |
| Thickness | 0.1-300mm |
| Width | 100-3000mm |
| Length | Coils /According to customer requirements |
| Surface | Smooth and flat , Embossed, Polished, Mirror, Bright, Polished, Hair line, Brush, Sand blast, Checkered, Etching, etc |
| Advantage | 1. Good malleability 2. Light-weight 3.Good electrical and thermal conductivity 4. High reflexes and oxidation resistance |
| Application | 1. Widely used in aircraft, cars, trains, ships and other manufacturing industries. In addition, space rocket, space shuttle,artificial satellite also use a large number of aluminum and its aluminum alloy 2. Electrical appliance manufacturing industry, wire and cable industry and radio industry 3. Manufacture all kinds of heat exchangers, cooling materials and cookers 4. Medical instruments, refrigeration units, ceilings in building interiors,Etc. |
| Payment Term | TT/LC/After Copy of the BL |
| Delivery Time | Within 3 days for our stock size,15-20days for our production |
| MOQ | 5 tons |
| Sample | Free and available |
| 5754 Chemical Composition | |||||||||
| Al | Si | Cu | Mg | Zn | Mn | Cr | Ni | Ti | Fe |
| Margin | ≤0.40 | ≤0.10 | 2.6~3.6 | ≤0.20 | ≤0.50 | ≤0.30 | --- | ≤0.15 | ≤0.40 |
1.Excellent corrosion resistance.
Due to the addition of Mg alloy components, the 5754 aluminum coil is better resistant to industrial and marine atmosphere, as well as water corrosion.
2.Excellent surface workability.
The surface of the 5754 aluminum coil can be processed with various processing methods. For example, the 5754 aluminum checker coil after the roller printing process is amazing!
3.Other features.
5754 aluminum coil tensile strength σb (MPa): 165～265, yield strength σb (MPa): ≥526180, good formability, strong plasticity, easy to process, etc.
1.Quality Assurance
Select the right ingredients, Cast product
2.Diversified Product
Product specifications and models are diverse, can meet customer's requirement
3.Adequate Stock
Multiple warehouses,timely delivery
4.After-Sale Guarantee
There are independent teams to solve problems for you
For Sound Barriers
5754 aluminum alloy is one of the two main sound barrier materials for railway/high-speed/subway and other transportation roads. 5754 aluminum coil sheet for sound barriers has good corrosion resistance and weather resistance, no low temperature brittleness, obvious sound insulation effect, durable and so on!
Other Usages
In addition, 5754 aluminum coil can also be used for Automotive aluminum, tank, Welded structures, storage tanks, pressure vessels, ship structures and offshore installations, transportation tanks, and applications where excellent processing performance, excellent corrosion resistance, high fatigue strength, high weldability, and moderate static strength are required. Used in high-speed railway noise barriers, tank materials, alloy doors and windows, aluminum for construction, aluminum for transportation, aluminum for automobiles and other fields.
1.The aluminum is placed with waterproof paper, and steel strip packed, which is suit for all kinds of transport, or as required.
2.Port: Qingdao, Shanghai or your request.
3.Container:
20 FT GP: 5988 mm (length) x 2352 mm (width) x 2393 mm (height), loading 18 to 25 tons.
40 FT GP: 12032 mm (length) x 2352 mm (width) x 2393 mm (height), loading 20 to 28 tons.
We are factory wholesale price, and the prices are lower than 95% of suppliers. Our professional quotation will help you with your project. Expecting our long-term cooperation. ）
