Diameter: 5-800mm, or as customer’s requirements.
Length: 0-6000mm, or as requirement.
Material: 1050, 1060, 1070, 1080, 1100, 1235, 2011, 2014, 2017, 2024, 2A12, 2A16, 2A06, 3002, 3003, 3004, 3004, 3104, 3204, 3030, 3A21, 5005, 5025, 5040, 5052, 5056, 5083, 5086, 5182, 5754, 5A05, 6003, 6060, 6061, 6082, 6083, 6063, 6061, 7003, 8006, 8011, 8021, 8079.
Standard: JIS, AISI, ASTM, GB, DIN, EN, etc.
Stock: 4000 Ton/Month.
Quality control: Third Part Inspection is acceptable.
Delivery Time: Within 3 days for our stock size, 15-20days for our production.
6061 aluminium alloy is the main alloy of magnesium and silicon, and the formation of Mg2Si phase. If you contain a certain amount of manganese and chromium, can neutralize the bad role of iron; sometimes add a small amount of copper or zinc, in order to improve the strength of the alloy, but not to significantly reduce the corrosion resistance; conductive materials, there are a small amount Of copper to offset the adverse effects of titanium and iron on the conductivity; zirconium or titanium can refine the grain and control the recrystallization structure; in order to improve the machinability, lead and bismuth can be added. In the Mg2Si solid solution in aluminum, so that the alloy has artificial aging hardening function. 6061 aluminum alloy in the main alloy elements for the magnesium and silicon, with moderate strength, good corrosion resistance, weldability, oxidation effect is better.
| Product Name | 6061 Aluminum Bar |
| Standard | ASTM, JIS, SUS, EN, DIN, GB, etc. |
| Alloy | 1100/1050/1060/1070/1200/1350 2011/2014/2017/2024/2A12/2219/2A16 3003/3004/3104/3005/3105/3A21 4A01/4032 5005/5049/5052/5082/5083/5154/5182/5251/5454/5754/5A05 6061/6082/6063/6K61/6Z61 7001/7072/7075/7085 8011 |
| Diameter | 10-50mm, 52-150mm, 155-250mm, 255-500mm, 550-700mm |
| Normal Diameter: | 73mm, 80mm, 85mm, 90mm, 100mm, 110mm, 114mm, 120mm, 125mm, 127mm, 130mm, 140mm, 152mm, 162mm, 178mm, 203mm, 228mm, 248mm, 252mm, 300mm, 305mm, 307mm, 380mm |
| Length | 0-6000mm, or as requirement |
| Process | Hot rolled & Cold rolled |
| Surface | Bright, polished, hair line, brush, embossed, etc |
| Temper | HO, H12, H14, H16, H18, H19, H22, H24, H26, H28, H112, T651, T3,T 451, T4, T6, ect. |
| Package | Export wooden pallents, craft paper, anti-blushing agent. |
| Inspection | 1.Foundry in-house: 100% inspection on critical dimension; 100% on appearance. 2.Third Party inspection available upon requirement. |
| Supply Ability | 30,000 tons every year. |
| Delivery Time | Within 3 days for our stock size,15-20days for our production. |
| MOQ | 5 tons. |
| Sample | Free and available. |
| Services | 1. Help customers to open new mould; 2. Help customers to design and revise suitable drawings; 3. Precision cutting and bending service is provided; 4. CNC machining such as drilling, milling, punching is provided. |
| 6061 Chemical Composition | |||||||||||||
| Al | Si | Fe | Cu | Mn | Mg | Cr | Ni | Zn | Ti | Zr | Pb | Max | Total |
| Margin | 0.40-0.80 | 0.7 | 0.15-0.40 | 0.15 | 0.80-1.20 | 0.04-0.35 | - | 0.25 | 0.15 | - | - | 0.05 | 0.15 |
| Mechanical Property | ||||||||
| Aluminum | Grade | Normal | Temper | Tensile Strength | Yield Strength | Elongation% | Brinell Hardness | |
| Alloy | Temper | N/mm | N/mm | Plate | Bar | HB | ||
| 1XXX | 1050 | O,H112,H | O | 78 | 34 | 40 | - | 20 |
| 1060 | O,H112,H | O | 70 | 30 | 43 | - | 19 | |
| Al-Cu | 2019 | O,T3,T4,T6,T8 | T851 | 450 | 350 | 10 | - | - |
| (2XXX) | 2024 | O,T4 | T4 | 470 | 325 | 20 | 17 | 120 |
| Al-Mn | 3003 | O,H112,H | O | 110 | 40 | 30 | 37 | 28 |
| (3XXX) | 3004 | O,H112,H | O | 180 | 70 | 20 | 22 | 45 |
| Al-Si (4XXX) | 4032 | O,T6,T62 | T6 | 380 | 315 | - | 9 | 120 |
| Al-Mg | 5052 | O,H112,H | H34 | 260 | 215 | 10 | 12 | 68 |
| (5XXX) | 5083 | O,H112,H | O | 290 | 145 | - | 20 | - |
| Al-Mg-Si | 6061 | O,T4,T6,T8 | T6 | 310 | 275 | 12 | 15 | 95 |
| (6XXX) | 6063 | O,T1,T5,T6,T8 | T5 | 185 | 145 | 12 | - | 60 |
| Al-Zn-Mg | 7003 | T5 | T5 | 315 | 255 | 15 | - | 85 |
| (7XXX) | 7075 | O,T6 | T6 | 570 | 505 | 11 | 9 | 150 |
1. There are no macular or roll marks on the surface of aluminum sheets.
2. There is no water corrosion on the surface.
3. The surface of aluminum sheets is very clean without lots of impurities.
We have a strict quality control system to ensure good product quality.
Our company has a large inventory and can deliver goods quickly.
1. 20 years production experience.
2. Factory direct sales with competitive price.
3. Customized service,having your own logo,packing and product style.
4. Urgent products,we could send items ASAP from our stock.
Aluminum tubes are widely used in all walks of life, such as automobiles, ships, spaceflight, aviation, electrical appliances, agriculture, mechanical and electrical, home and so on.
1.Standard seaworthy export packing, wooden pallets with plastics protection for our aluminium products.
2. The other packing can be made based on the customer requirement.
3. Normally, we have four layers of packing: wooden pallets, hardboard, Kraft paper and plastic. And fill more desiccants into package.
4. Container size:
20ft GP: 5898mm(Length)x2352mm(Width)x2393mm(High) 24-26CBM.
40ft GP: 12032mm(Length)x2352mm(Width)x2393mm(High) 54CBM.
40ft HC: 12032mm(Length)x2352mm(Width)x2698mm(High) 68CBM.
We are factory wholesale price, and the prices are lower than 95% of suppliers. Our professional quotation will help you with your project. Expecting our long-term cooperation. ）
